In an article recently published in Desalination, researchers investigated the effectiveness of salt-free electrodialysis metathesis (SF-EDM) as a novel method for managing brine in brackish water desalination. This innovative process aims to increase water recovery rates and reduce the environmental impact of traditional desalination methods, particularly the disposal of high-salinity waste/concentrates. The study highlighted the potential of SF-EDM to improve water treatment and resource recovery practices.
Addressing Global Water Scarcity
Desalination has become increasingly important in addressing global water scarcity, particularly in regions with limited freshwater resources. Reverse osmosis (RO) is the most widely used among various desalination methods due to its energy efficiency and decreasing costs. However, RO systems generally recover only 70-85% of the water, leaving the remaining 15% as concentrated brine, posing significant disposal challenges. This high-salinity waste can result in serious environmental risks if not appropriately managed.
The conventional disposal methods, such as deep-well injection and evaporation ponds, risk environmental contamination and lead to the loss of valuable minerals and metals, such as lithium, which are crucial for various technological applications.
Electrodialysis (ED) offers an alternative ion-removal method. It utilizes an electric field and ion-exchange membranes to separate ions from water. This technique has been employed for over six decades in applications like brackish water desalination and wastewater treatment.
Conventional electrodialysis metathesis (EDM) has been used in zero discharge desalination (ZDD) systems, but it often requires sodium chloride (NaCl) as a substitute solution, complicating the treatment of concentrates. Introducing salt-free electrodialysis metathesis (SF-EDM) eliminates the need for NaCl, providing a more sustainable and efficient approach to desalination.
Using SF-EDM to Improve Water Recovery
In this paper, the authors evaluated SF-EDM as a secondary process to improve water recovery in desalination, comparing it to traditional EDM within the framework of zero discharge desalination. They conducted a series of laboratory-scale experiments using synthetic and real reverse osmosis concentrates to examine the operational parameters, limitations, and overall effectiveness of the SF-EDM process. The primary objectives were to assess salinity reduction, ion selectivity, and energy consumption during SF-EDM operation.
The study used monovalent-selective ion-exchange membranes to achieve these goals in a two-pass desalination process. This design allowed the production of one diluate stream and two concentrate streams enriched in calcium and sulfate, respectively.
The membranes selectively allowed ions to pass through, improving salt removal efficiency from water.
The experimental setup included continuous monitoring of the diluate's conductivity to evaluate the effectiveness of salinity reduction over time.
The researchers optimized operational parameters to maximize water recovery while addressing challenges like scaling, common in conventional desalination methods.
Outcomes of Using SF-EDM Technique
The study showed that the SF-EDM process achieved a remarkable salinity reduction of over 90%, reaching 93% in the experimental trials. This efficiency was coupled with a total system water recovery rate of 90%, combining reverse osmosis and SF-EDM processes. The specific energy consumption ranged from 1 to 7 kWh/m³, indicating a favorable energy profile compared to traditional desalination methods.
A key finding was this method's ability to selectively separate ions. It effectively distinguishes between monovalent and divalent ions, allowing sulfate and calcium to be separated into distinct concentrate streams. This selectivity is particularly important for applications such as irrigation, where it helps prevent sodium accumulation in agricultural soils.
The techno-economic analysis further highlighted the benefits of SF-EDM. The levelized cost of water produced was about 80% lower than that of conventional EDM systems, making it an economically viable option for brine management in desalination projects. These results suggest that the presented process improves water recovery and reduces operational costs and environmental impacts of concentrate disposal.
Applications
The implications of this research extend beyond brine management in desalination. The ability to achieve high water recovery rates while selectively removing harmful ions makes SF-EDM a promising solution for various applications, including agricultural irrigation and industrial water reuse.
This technology can provide a reliable source of fresh water, boosting agricultural productivity and supporting food security in drought-prone regions. It has the potential to contribute to resource recovery by enabling the extraction of valuable minerals from brine, enhancing the economic viability of desalination projects.
Conclusion and Future Directions
The SF-EDM method significantly enhanced water recovery rates while reducing operational costs and the environmental impacts of brine disposal.
Water scarcity remains a growing challenge for communities worldwide; adopting technologies like SF-EDM could be crucial in sustainable water management. Future work should focus on scaling the technology for real-world applications and optimizing the process to maximize efficiency and resource recovery.
Disclaimer: The views expressed here are those of the author expressed in their private capacity and do not necessarily represent the views of AZoM.com Limited T/A AZoNetwork the owner and operator of this website. This disclaimer forms part of the Terms and conditions of use of this website.
Source:
Oddonetto, T, L., & et al. Assessment of salt-free electrodialysis metathesis: A novel process for brine management in brackish water desalination using monovalent selective ion exchange membranes. Desalination, 2024, 592, 118160. DOI: 10.1016/j.desal.2024.118160, https://www.sciencedirect.com/science/article/abs/pii/S0011916424008713
