Mar 10 2008
Scientists at the U.S. Department of Energy's Brookhaven National Laboratory and the Institute for Molecular Science in Japan are trying to mimic part of the complex natural process of photosynthesis with the goal of making non-polluting fuels such as hydrogen, for example, for use in fuel cells. In the March 10, 2008, web release of the journal Inorganic Chemistry containing a Forum on "Making Oxygen," the scientists report they were able to mimic the "water oxidation catalysis" that occurs in natural photosynthesis.
James Muckerman (left) and Etsuko Fujita.
Water oxidation, a step in photosynthesis, is one part of "water-splitting" -- splitting water into hydrogen and oxygen, a very complex process. Water-splitting requires a large amount of energy from sunlight and metal catalysts to activate the very stable water molecules. It occurs as two separate "half" reactions: water oxidation produces the oxygen, along with protons and electrons; these protons and electrons are then combined to make molecular hydrogen.
"The water oxidation reaction is generally believed to be the 'limiting' process, meaning that if it is not catalyzed efficiently, it limits hydrogen production," said Brookhaven chemist James Muckerman, co-author on the current paper. "You can't sustain hydrogen production without the protons and electrons generated by water oxidation. So, to make hydrogen from water for use in fuel cells, we must meet the challenge of performing efficient and inexpensive water oxidation," Muckerman said.
Brookhaven chemist Etsuko Fujita, co-author on the paper, explains how the Brookhaven team has been collaborating with Japanese scientists Koji Tanaka and Tohru Wada, who in 2001 discovered a novel catalyst that appears quite promising for water oxidation.
"We are combining theoretical and experimental studies to determine how this ruthenium complex with bound quinone molecules efficiently catalyzes water oxidation to form oxygen," she said.
To accomplish the water-oxidation reaction, Tanaka and Wada immobilized the ruthenium catalyst on an electrode, placed it in an aqueous solution, and applied a voltage, resulting in a rapid turnover for oxidizing water to oxygen. The research team, which also includes Brookhaven's Dmitry Polyansky, continues to collaborate on further studies to understand the details of how the catalyst works.
The scientists have discovered that when the protons from two water molecules are removed due to acid-base reactions in solution, four electrons are transferred to electron receptor sites in the catalyst. Once all the protons are removed, the theoretical calculations predict that an oxygen-oxygen bond is formed.
What makes their catalyst "novel" is that in most metal-based compound catalysts these electron receptor sites are located on the metal atoms, but in this ruthenium complex the receptor sites are on the quinone molecules. More theoretical and experimental studies will be needed to fully understand and improve the mechanisms of quinone-containing catalysts.
The Benefits
Producing hydrogen from water would offer several benefits over current methods, including steam reforming of natural gas, which produces carbon dioxide along with the hydrogen. Heat derived from fossil-fuel combustion is currently used to drive the steam reforming process, resulting in even more carbon dioxide as a byproduct, all of which contributes to global warming. Making hydrogen by splitting water would not add carbon dioxide to the atmosphere.
Additionally, hydrogen produced from natural gas contains residual carbon monoxide, which can "poison" the expensive electrodes in fuel cells, requiring their replacement. Hydrogen produced from water does not contain carbon monoxide, and therefore does not subject fuel cell electrodes to poisoning.
"The ruthenium in our catalyst is somewhat expensive, so we plan to continue our studies with more economical catalysts incorporating less-expensive metals," Muckerman said.
Hydrogen made by water splitting could also be used directly for combustion in a future hydrogen-based economy.
The U.S. Department of Energy's Office of Basic Energy Sciences (BES) within its Office of Science funded this basic research at Brookhaven Lab. The research is part of the BES Hydrogen Fuel Initiative program.
